Tee Type Strainer Manufacturers
The Tee type strainer is a simple yet effective device for filtering foreign particles from a process liquid. As the name suggests, the strainer has a Tee-shaped body, with a perforated or wire mesh basket placed inside. The basket filters out the suspended particles from the process liquid, allowing only clean fluid to pass through.
The Tee type strainer is one of the most popular strainers used in industries due to its simplicity and capacity to work under high-pressure conditions. Some industries where it finds applications are power generation, pharmaceuticals, etc.
Thanks to its widespread use, the Tee type strainer plays an essential role in ensuring the quality of products and protecting equipment from damage.
- Size : Upto 1200 NB
- Pressure : Upto 60 Kg/CM²
- Temperature : Upto 600°C.
- Mesh Size : 5 to 500 microns
Technical Specifications
| Material of Wetted Parts | ASTM A216 Gr WCB/ASTMA 351CF8/ASTMA 351CF8M/MS/CS/ SS304/SS304L/SS316/SS316L/PP & HDPE |
| Filter Elements | SS316/SS316 L/SS304/SS304 L/PTFE/PP |
| Connection | Flanged to ASA/BS/DIN/JIS/Screwed BSP/NPT/Butt Weld |
Design Features
- Carbon steel and stainless steel materials of construction Available
- Minimum Pressure Drop
- Free Straining area is more than 2.5 times the pipe cross section area
- Differential and drains optional
- Casting and Fabricated body shall be done
- Body of MOC shall be of Gun Metal, A216 WCB, SS, CS, etc
Product Applications
- Chemical Processing
- Petroleum
- Power Generation
- Marine
- Oil & Gas
- Iron & Steel
- HVAC
- Food & Beverage
- Pharmaceutical
