Cable Float Level Switch Manufacturers
The Cable type Float Level Switch is made from chemical-resistant polypropylene. It is durable, low-cost, and specially designed to assist with long-range and multiple-point level detection in fluids.
The switch contains a float that can slide as the float position changes. This change is used to detect the level of the fluid. They are then used to turn on and off the medium flow in the containers they are installed in.
They are used in a wide range of industries and can work with clear and granular fluids, making them very robust and versatile.
- IP68 Housing
- Heavy Duty - ABS
- SPDT 1- NO, 1-NC Output
- Rated for 50,000 Operations
- Rated switching of 10A 240VAC
Technical Specifications
| Contact Form/ Style | Mechanical Switching |
| Rated Switching Voltage | Max. 380 VAC |
| Rated Switching Capacity | S10A at 240 VAC / 6A at 380 VAC |
| Output Type | SPDT (1 NO/ 1 NC) |
| Contact Resistance | Max. 3.0 ¥® |
| Differential Angle | 45° |
| Rated no. of Operations | 50000 |
| Ambient Temperature | -25 °C to +70 °C |
| Protection Degree | IP68 |
| Net. Weight | 500 Grams |
| Material | ABS or eqv. |
| Cable Length | 2m, 5m |
Mounting & Operation
- Float switch floats in the liquid medium and needs a counterweight that will act as a pivot.
- Pass the cable through the counter weight and insert the stoppers provided once the desired swing length is reached.
- Differential is the height required for the switch to operate the height can be varied by changing the length of cable after the counter weight
- The switch may not work if the medium has a lower specific gravity than water.
